Gigabyte B450M DS3H V2 vs MSI PRO B760M-A WIFI DDR4
Key differences
- MSI PRO B760M-A WIFI DDR4: ethernet 2.5 Gbps vs 1 Gbps (60% higher)
- MSI PRO B760M-A WIFI DDR4: m.2 slots 2 vs 1 (50% higher)
- MSI PRO B760M-A WIFI DDR4: max memory speed 5,333 MT/s vs 3,600 MT/s (32% higher)
Same on both: usb4 No, rear usb-c 0, sata ports 4, form factor Micro-ATX, memory type DDR4, max memory 128 GB, memory slots 4.
| Gigabyte B450M DS3H V2 | MSI PRO B760M-A WIFI DDR4 | |
|---|---|---|
| Released | — | 2023 |
| USB4 | No | No |
| Wi-Fi | — | Wi-Fi 6E |
| Socket | AM4 | LGA1700 |
| Chipset | B450 | B760 |
| Ethernet | 1 Gbps | 2.5 Gbps |
| M.2 slots | 1 | 2 |
| Rear USB | 4× 5Gb/s Type-A, 4× USB 2.0 | 2× 10Gb/s Type-A, 2× 5Gb/s Type-A, 2× USB 2.0 |
| Rear USB-A | 8 | 6 |
| Rear USB-C | 0 | 0 |
| PCIe slots | 1× x16, 1× x4 (x16 slot), 1× x1 | 1× PCIe 4.0 x16, 1× PCIe 4.0 x4 (x16 slot), 1× PCIe 3.0 x1 |
| SATA ports | 4 | 4 |
| Fan headers | 2 | 4 |
| Form factor | Micro-ATX | Micro-ATX |
| Memory type | DDR4 | DDR4 |
| GPU slot | PCIe 3.0 | PCIe 4.0 |
| RGB headers | 1× RGB | 2× ARGB, 1× RGB |
| Internal USB headers | 2× 5Gb/s ports, 4× USB 2.0 ports | 1× 5Gb/s Type-C, 4× 5Gb/s ports, 4× USB 2.0 ports |
| Max memory | 128 GB | 128 GB |
| Memory slots | 4 | 4 |
| Thunderbolt / USB4 | — | — |
| Ethernet controller | Realtek 1Gb | Realtek RTL8125BG 2.5Gb |
| Video outputs | 1× HDMI, 1× DVI-D | 2× HDMI 2.1, 2× DisplayPort 1.4 |
| Front USB-C header | — | 5Gb/s |
| Max memory speed | 3,600 MT/s | 5,333 MT/s |
| PCIe 5.0 M.2 slots | — | 0 |
| M.2 slots (detail) | — | 2× PCIe 4.0 x4 |
| Bluetooth | — | 5.3 |
| Audio | — | Realtek ALC897 |
