Gigabyte B550 AORUS ELITE AX V2 vs MSI MPG B550I GAMING EDGE WIFI
Key differences
- Gigabyte B550 AORUS ELITE AX V2: max memory 128 GB vs 64 GB (50% higher)
- Gigabyte B550 AORUS ELITE AX V2: memory slots 4 vs 2 (50% higher)
- Gigabyte B550 AORUS ELITE AX V2: max memory speed 4,733 MT/s vs 4,600 MT/s
Same on both: usb4 No, pcie 5.0 m.2 slots 0, socket AM4, chipset B550, ethernet 2.5 Gbps, m.2 slots 2, m.2 slots (detail) 1× PCIe 4.0 x4, 1× PCIe 3.0 x4, sata ports 4, memory type DDR4, gpu slot PCIe 4.0, bios flashback Yes, front usb-c header 5Gb/s.
| Gigabyte B550 AORUS ELITE AX V2 | MSI MPG B550I GAMING EDGE WIFI | |
|---|---|---|
| Released | 2021 | 2020 |
| USB4 | No | No |
| Wi-Fi | Wi-Fi 6E | — |
| PCIe 5.0 M.2 slots | 0 | 0 |
| Socket | AM4 | AM4 |
| Chipset | B550 | B550 |
| Ethernet | 2.5 Gbps | 2.5 Gbps |
| M.2 slots | 2 | 2 |
| Rear USB | 2× 10Gb/s Type-A, 3× 5Gb/s Type-A, 2× USB 2.0 | 1× 10Gb/s Type-C, 1× 10Gb/s Type-A, 2× 5Gb/s Type-A, 2× USB 2.0 |
| M.2 slots (detail) | 1× PCIe 4.0 x4, 1× PCIe 3.0 x4 | 1× PCIe 4.0 x4, 1× PCIe 3.0 x4 |
| Rear USB-A | 7 | 5 |
| Rear USB-C | 0 | 1 |
| Bluetooth | 5.3 | 5.2 |
| PCIe slots | 1× PCIe 4.0 x16, 1× PCIe 3.0 x2 (x16 slot), 1× PCIe 3.0 x1 (x16 slot), 1× PCIe 3.0 x1 | 1× PCIe 4.0 x16 |
| SATA ports | 4 | 4 |
| Fan headers | 5 | 3 |
| Form factor | ATX | Mini-ITX |
| Memory type | DDR4 | DDR4 |
| GPU slot | PCIe 4.0 | PCIe 4.0 |
| RGB headers | 2× ARGB, 3× RGB | 1× ARGB |
| Internal USB headers | 1× 5Gb/s Type-C, 2× 5Gb/s ports, 4× USB 2.0 ports | 1× 5Gb/s Type-C, 2× 5Gb/s ports, 2× USB 2.0 ports |
| Max memory | 128 GB | 64 GB |
| Memory slots | 4 | 2 |
| Thunderbolt / USB4 | — | — |
| BIOS flashback | Yes | Yes |
| Ethernet controller | Realtek 2.5Gb | Realtek RTL8125B 2.5Gb |
| Video outputs | 1× HDMI, 1× DisplayPort | 1× HDMI |
| Front USB-C header | 5Gb/s | 5Gb/s |
| Max memory speed | 4,733 MT/s | 4,600 MT/s |
| Audio | — | Realtek ALC1200 |
